Order Code: SGX500ONWG
SIGNUM X Linear System Grey 45W - Opal Diffuser - Fixed Output - 4000K
Technical Data
Luminaire Wattage (W) 45
Weight (kg) 4.50
Operating Temperature (°C) 0 to 25
Lumens (lm) 3700
Efficacy (lm/W) 111
L90 Lifetime (HRS) 38000
L80 Lifetime (HRS) 72000
L70 Lifetime (HRS) 72000
Rated Input Current (A) 0.21
Power Factor (pf) 0.94
Input Voltage Range (VAC) 220 - 240
Inrush Current Peak (A) 33
Surge Protection (kV) 1
Total Harmonic Distortion (THD) 20
Output LF Ripple ±5%
Conductor Size (mm) 0.5 to 2.5
Terminal Type 5-pole grip-wire
CCT (K) 4000
CRI 80
Macadam Elipses <3
Driver Current (mA) 275
Forward Voltage (V) 59
Driver Lifetime (HRS) 100000
Features
- Efficacy - 111 lm/W
- System Configuration: Supports standalone or continuous runs with T, X and corner modules for layout flexibility
- Energy Efficiency: Achieves up to 111 lm/W (lumens per watt) output
- Smart Integration: Compatible with Tamlite’s VISION lighting controls
Construction
- Construction: Lightweight extruded aluminium housing finished in White (RAL 9016), Grey (RAL 9006) or Black (RAL 9005) for durability and sustainability.
- Colour Temperature: Supplied in neutral white (4000K)
- Opal Diffuser: Soft, even light for general illumination
To Specify
SIGNUM X Linear System Grey 45W - Opal Diffuser - Fixed Output - 4000K as per Tamlite SIGNUM X O range.
