Order Code: NEP210NWM3
NEPTUNE - Circular Bulkhead - 17W - Opal diffuser - 4000K - White - Fixed output - Emergency
Technical Data
Luminaire Wattage (W) 17
Weight (kg) 2.10
Operating Temperature (°C) 5 to +25 °C
Lumens (lm) 2100
Efficacy (lm/W) 122
L90 Lifetime (HRS) >54000
L80 Lifetime (HRS) >54000
L70 Lifetime (HRS) >54000
Rated Input Current (A) 0.08
Power Factor (pf) 0.96
Input Voltage Range (VAC) 220 to 240
Inrush Current Peak (A) 210?s
Surge Protection (kV) 1kV
Total Harmonic Distortion (THD) < 15 %
Output LF Ripple ± 5 %
Conductor Size (mm) 0.5 to 2.5
Terminal Type 4 to Pole Piano
CCT (K) 4000k
CRI 85
Macadam Elipses <3.3
Driver Current (mA) 600
Forward Voltage (V) 24.0 to 24.2Vdc
Driver Lifetime (HRS) 100,000
Emergency Lumen Operating 366
Emergency Wattage (W) 3
Features
- Energy Efficiency: Achieves up to 122 lm/W (lumens per watt) output
- Lumen Output: Available in 1600 lm or 2100 lm
- Smart Integration: Compatible with Tamlite’s VISION lighting controls
- Application: Suitable for communal areas, corridors, stairwells and wet environments
Construction
- Colour Temperature: Available in Warm White (3000K) or Neutral White (4000K)
- Opal Diffuser: Soft, even light for general illumination
- Construction: Polycarbonate housing in White (RAL 9016)
- Conduit Entry: Flat side and rear entry with BESA fixings for versatile installation
- Easy Install: Snap-fit, peel-off trim with twist-lock diffuser
To Specify
NEPTUNE - Circular Bulkhead - 17W - Opal diffuser - 4000K - White - Fixed output - Emergency as per Tamlite NEPTUNE range.
