Order Code: APX17400AWNWD
APEX - Grey - 1200W - Asymmetric Wide - 4000K - Dimmable DALI
Technical Data
Luminaire Wattage (W) 1200
Weight (kg) 16.60
Operating Temperature (°C) ?40°C~+50°C @Outdoor
Lumens (lm) 173806
Efficacy (lm/W) 145
Beam Angle (FWHM°) 60
L90 Lifetime (HRS) 44,400
L70 Lifetime (HRS) >102000
Rated Input Current (A) 5.22 A ±3%
Power Factor (pf) ?0.9
Input Voltage Range (V) 220 to 400 V
Surge Protection (kV) 10KV
Total Harmonic Distortion (THD) < 10%
Output LF Ripple ? 1
Conductor Size (mm) 1.0
Terminal Type PUSH FIX
CCT (K) 4000
CRI 80
Macadam Elipses ?5
Driver Current (mA) 3430 mA ±5%
Forward Voltage (V) 336 V ±5%
Driver Lifetime (HRS) 100,000
Features
- Exceptional Optical Performance
Advanced optics provide precise light distribution and excellent uniformity, helping maximise visibility across sports facilities - Lightweight Construction
An optimised lightweight design improves handling on site, helping make installation and servicing quicker and safer. - Remote Driver
Allows the control gear to be mounted up to 100m from the luminaire, improving accessibility for installation and future servicing. - High Output Performance
Delivering up to 174,000 lumens at up to 145 lm/W, providing powerful illumination while helping reduce energy consumption and operating costs
Construction
- Precision Aiming
5° incremental adjustment allows accurate beam positioning to achieve optimum light distribution. - DALI Dimmable
Supports DALI dimming and is compatible with DMX control systems for flexible lighting management. - IP66 & IK08 Rated
Designed to withstand harsh outdoor environments with excellent protection against water, dust and impact. - Long Service Life
A 100,000 hour rated lifetime helps minimise maintenance requirements and reduce whole life costs
To Specify
APEX - Grey - 1200W - Asymmetric Wide - 4000K - Dimmable DALI as per Tamlite APEX range.
