SIGNUM R O
Recessed Linear System with Opal Diffuser
- Available in 2 module lengths and 3 colour options
- Available with opal or microprism optic
- Integrated emergency option available
- Connection accessories to create dynamic systems
- Supplied as stand-alone or continuous versions
- Recessed linear system for office, libraries and large open areas
- CRI: Ra>80
- Extruded aluminium body finished in white (RAL 9016), grey (RAL 9006) or black (RAL 9005)
- Opal PMMA diffuser
- Up to 121 lumens per Watt efficacy
Product Filter
If you don’t have a part number, use the filter to find what you need. Select product and light source first to narrow the output and power options.
| Order Code | Description | lm | W | lm/W | L(mm) | W(mm) | D(mm) |
|---|---|---|---|---|---|---|---|
| SGR4230ONWB | 19W - Opal Diffuser - 4000K - Black | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWBA3 | 19W - Opal Diffuser - 4000K - Black | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWBD | 19W - Opal Diffuser - 4000K - Black | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWBD3 | 19W - Opal Diffuser - 4000K - Black | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWBDA3 | 19W - Opal Diffuser - 4000K - Black | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWBDD3 | 19W - Opal Diffuser - 4000K - Black | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWBDM3 | 19W - Opal Diffuser - 4000K - Black | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWBM3 | 19W - Opal Diffuser - 4000K - Black | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWG | 19W - Opal Diffuser - 4000K - Grey | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWGA3 | 19W - Opal Diffuser - 4000K - Grey | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWGD | 19W - Opal Diffuser - 4000K - Grey | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWGD3 | 19W - Opal Diffuser - 4000K - Grey | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWGDA3 | 19W - Opal Diffuser - 4000K - Grey | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWGDD3 | 19W - Opal Diffuser - 4000K - Grey | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWGDM3 | 19W - Opal Diffuser - 4000K - Grey | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWGM3 | 19W - Opal Diffuser - 4000K - Grey | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWW | 19W - Opal Diffuser - 4000K - White | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWWA3 | 19W - Opal Diffuser - 4000K - White | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWWD | 19W - Opal Diffuser - 4000K - White | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWWD3 | 19W - Opal Diffuser - 4000K - White | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWWDA3 | 19W - Opal Diffuser - 4000K - White | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWWDD3 | 19W - Opal Diffuser - 4000K - White | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWWDM3 | 19W - Opal Diffuser - 4000K - White | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR4230ONWWM3 | 19W - Opal Diffuser - 4000K - White | 2300 | 19 | 121 | 1085 | 73 | 75 |
| SGR5340ONWB | 28W - Opal Diffuser - 4000K - Black | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWBA3 | 28W - Opal Diffuser - 4000K - Black | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWBD | 28W - Opal Diffuser - 4000K - Black | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWBD3 | 28W - Opal Diffuser - 4000K - Black | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWBDA3 | 28W - Opal Diffuser - 4000K - Black | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWBDD3 | 28W - Opal Diffuser - 4000K - Black | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWBDM3 | 28W - Opal Diffuser - 4000K - Black | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWBM3 | 28W - Opal Diffuser - 4000K - Black | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWG | 28W - Opal Diffuser - 4000K - Grey | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWGA3 | 28W - Opal Diffuser - 4000K - Grey | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWGD | 28W - Opal Diffuser - 4000K - Grey | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWGD3 | 28W - Opal Diffuser - 4000K - Grey | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWGDA3 | 28W - Opal Diffuser - 4000K - Grey | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWGDD3 | 28W - Opal Diffuser - 4000K - Grey | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWGDM3 | 28W - Opal Diffuser - 4000K - Grey | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWGM3 | 28W - Opal Diffuser - 4000K - Grey | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWW | 28W - Opal Diffuser - 4000K - White | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWWA3 | 28W - Opal Diffuser - 4000K - White | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWWD | 28W - Opal Diffuser - 4000K - White | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWWD3 | 28W - Opal Diffuser - 4000K - White | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWWDA3 | 28W - Opal Diffuser - 4000K - White | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWWDD3 | 28W - Opal Diffuser - 4000K - White | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWWDM3 | 28W - Opal Diffuser - 4000K - White | 3400 | 28 | 121 | 1625 | 73 | 75 |
| SGR5340ONWWM3 | 28W - Opal Diffuser - 4000K - White | 3400 | 28 | 121 | 1625 | 73 | 75 |
