SIGNUM R
Recessed Linear System with Micro-prism Diffuser
- TM66 Certified options available for specification
- Available in 2 module lengths and 3 colour options
- Available with opal or microprism optic
- Integrated emergency option available
- Connection accessories to create dynamic systems
- Supplied as stand-alone or continuous versions
- Recessed linear system for office, libraries and large open areas
- CRI: Ra>80
- Extruded aluminium body finished in white (RAL 9016), grey (RAL 9006) or black (RAL 9005)
- Polycarbonate Tp(a) rated microprism diffuser
- Up to 132 lumens per Watt efficacy
Product Filter
If you don’t have a part number, use the filter to find what you need. Select product and light source first to narrow the output and power options.
| Order Code | Description | lm | W | lm/W | L(mm) | W(mm) | D(mm) |
|---|---|---|---|---|---|---|---|
| SGR4250MPNWB | 19W - Micro-prism Diffuser - 4000K - Black | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWBA3 | 19W - Micro-prism Diffuser - 4000K - Black | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWBD | 19W - Micro-prism Diffuser - 4000K - Black | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWBD3 | 19W - Micro-prism Diffuser - 4000K - Black | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWBDA3 | 19W - Micro-prism Diffuser - 4000K - Black | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWBDD3 | 19W - Micro-prism Diffuser - 4000K - Black | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWBDM3 | 19W - Micro-prism Diffuser - 4000K - Black | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWBM3 | 19W - Micro-prism Diffuser - 4000K - Black | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWG | 19W - Micro-prism Diffuser - 4000K - Grey | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWGA3 | 19W - Micro-prism Diffuser - 4000K - Grey | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWGD | 19W - Micro-prism Diffuser - 4000K - Grey | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWGD3 | 19W - Micro-prism Diffuser - 4000K - Grey | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWGDA3 | 19W - Micro-prism Diffuser - 4000K - Grey | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWGDD3 | 19W - Micro-prism Diffuser - 4000K - Grey | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWGDM3 | 19W - Micro-prism Diffuser - 4000K - Grey | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWGM3 | 19W - Micro-prism Diffuser - 4000K - Grey | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWW | 19W - Micro-prism Diffuser - 4000K - White | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWWA3 | 19W - Micro-prism Diffuser - 4000K - White | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWWD | 19W - Micro-prism Diffuser - 4000K - White | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWWD3 | 19W - Micro-prism Diffuser - 4000K - White | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWWDA3 | 19W - Micro-prism Diffuser - 4000K - White | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWWDD3 | 19W - Micro-prism Diffuser - 4000K - White | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWWDM3 | 19W - Micro-prism Diffuser - 4000K - White | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR4250MPNWWM3 | 19W - Micro-prism Diffuser - 4000K - White | 2500 | 19 | 132 | 1102 | 73 | 75 |
| SGR5370MPNWB | 28W - Micro-prism Diffuser - 4000K - Black | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWBA3 | 28W - Micro-prism Diffuser - 4000K - Black | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWBD | 28W - Micro-prism Diffuser - 4000K - Black | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWBD3 | 28W - Micro-prism Diffuser - 4000K - Black | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWBDA3 | 28W - Micro-prism Diffuser - 4000K - Black | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWBDD3 | 28W - Micro-prism Diffuser - 4000K - Black | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWBDM3 | 28W - Micro-prism Diffuser - 4000K - Black | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWBM3 | 28W - Micro-prism Diffuser - 4000K - Black | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWG | 28W - Micro-prism Diffuser - 4000K - Grey | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWGA3 | 28W - Micro-prism Diffuser - 4000K - Grey | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWGD | 28W - Micro-prism Diffuser - 4000K - Grey | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWGD3 | 28W - Micro-prism Diffuser - 4000K - Grey | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWGDA3 | 28W - Micro-prism Diffuser - 4000K - Grey | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWGDD3 | 28W - Micro-prism Diffuser - 4000K - Grey | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWGDM3 | 28W - Micro-prism Diffuser - 4000K - Grey | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWGM3 | 28W - Micro-prism Diffuser - 4000K - Grey | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWW | 28W - Micro-prism Diffuser - 4000K - White | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWWA3 | 28W - Micro-prism Diffuser - 4000K - White | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWWD | 28W - Micro-prism Diffuser - 4000K - White | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWWD3 | 28W - Micro-prism Diffuser - 4000K - White | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWWDA3 | 28W - Micro-prism Diffuser - 4000K - White | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWWDD3 | 28W - Micro-prism Diffuser - 4000K - White | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWWDM3 | 28W - Micro-prism Diffuser - 4000K - White | 3700 | 28 | 132 | 1642 | 73 | 75 |
| SGR5370MPNWWM3 | 28W - Micro-prism Diffuser - 4000K - White | 3700 | 28 | 132 | 1642 | 73 | 75 |
