SECURE D

Anti-ligature Recessed Downlight

  • Secure fitting built to prevent vulnerable people from accidently or intentionally self-harming
  • Suitable for low, medium and high risk secure services
  • Recessed fix
  • For use in hospital wards and corridors
  • Vandal-resistant and tamper-proof
  • Die-cast aluminium body finished in white (RAL 9010)
  • 6mm Clear polycarbonate diffuser secured by Resistorx screws
  • Integral driver simplifying installation
  • CRI: Ra>80
  • Integrated emergency option available
  • Supplied in neutral white (4000K) LED
  • Independently tested and certified to meet the requirements set out in the Department of Health Environmental Design Guide 2011 for Adult Medium Secure Services
  • Note: When product is supplied without a driver, the fitting is Class 3.
IP65IK145 Years Warranty2 Years On-Site Warranty (T&C`s Apply)Vision ConnectVision Air
Product Filter

If you don’t have a part number, use the filter to find what you need. Select product and light source first to narrow the output and power options.

Instruction leaflet
Polar Curve
Photometric Data
Order Code Description lm W lm/W Cut out Dia(mm) D(mm) Folio
SCD120NW 12W - 4000K 1200 12 96 185 250 143
SCD120NWA3 12W - 4000K 1200 12 96 185 250 143
SCD120NWD 12W - 4000K 1200 12 96 185 250 143
SCD120NWD3 12W - 4000K 1200 12 96 185 250 143
SCD120NWDA3 12W - 4000K 1200 12 96 185 250 143
SCD120NWDD3 12W - 4000K 1200 12 96 185 250 143
SCD120NWDM3 12W - 4000K 1200 12 96 185 250 143
SCD120NWM3 12W - 4000K 1200 12 96 185 250 143
SCD220NW 24W - 4000K 2200 24 95 185 250 143
SCD220NWA3 24W - 4000K 2200 24 95 185 250 143
SCD220NWD 24W - 4000K 2200 24 95 185 250 143
SCD220NWD3 24W - 4000K 2200 24 95 185 250 143
SCD220NWDA3 24W - 4000K 2200 24 95 185 250 143
SCD220NWDD3 24W - 4000K 2200 24 95 185 250 143
SCD220NWDM3 24W - 4000K 2200 24 95 185 250 143
SCD220NWM3 24W - 4000K 2200 24 95 185 250 143
SCD300NW 32W - 4000K 3000 32 96 185 250 143
SCD300NWA3 32W - 4000K 3000 32 96 185 250 143
SCD300NWD 32W - 4000K 3000 32 96 185 250 143
SCD300NWD3 32W - 4000K 3000 32 96 185 250 143
SCD300NWDA3 32W - 4000K 3000 32 96 185 250 143
SCD300NWDD3 32W - 4000K 3000 32 96 185 250 143
SCD300NWDM3 32W - 4000K 3000 32 96 185 250 143
SCD300NWM3 32W - 4000K 3000 32 96 185 250 143
