Mounting: Surface mount via rear entry or suspended with wire kit, BESA options available (specify when ordering)
Order Code: TMPO4270NWDM3
PRIMA Surface Module 17W - Dimmable DALI - Emergency - 4000K
Technical Data
Luminaire Wattage (W) 17
Weight (kg) 4.10
Operating Temperature (°C) 5 to 25
Lumens (lm) 2700
Efficacy (lm/W) 159
Beam Angle (FWHM°) 118
L90 Lifetime (HRS) 58000
L80 Lifetime (HRS) 72000
L70 Lifetime (HRS) 72000
Rated Input Current (A) 0.1
Power Factor (pf) 0.82
Input Voltage Range (VAC) 220 to 240
Inrush Current Peak (A) 22.4
Surge Protection (kV) 1
Total Harmonic Distortion (THD) <30%
Output LF Ripple ±2%
Conductor Size (mm) 0.5 to 2.5
Terminal Type 4-pole + 2-pole grip-wire
CCT (K) 4000
CRI 80
Macadam Elipses <3
Driver Current (mA) 125
Forward Voltage (V) 116 to 127
Driver Lifetime (HRS) 100000
Emergency Lumen Operating 390
Emergency Wattage (W) 3
Information
Download the Product Information Sheet
Download the ERP Instructions
View the full details on the EPREL website
Features
- Efficacy - 159 lm/W
- Applications: Suitable for offices and schools
- Energy Efficiency: Achieves up to 159 lm/W (lumens per watt) output
Installation Notes
Construction
- Colour Temperature: Supplied in Neutral White (4000K)
- Construction: Steel body finished in White (RAL 9016)
- Durability: Polycarbonate extruded diffuser with secured end caps and screw fixings
- Opal Diffuser: Soft, even light for general illumination
To Specify
PRIMA Surface Module 17W - Dimmable DALI - Emergency - 4000K as per Tamlite PRIMA range.
Our Commitment to TM66
Our commitment to excellence was recognised at the Electrical Industry Awards, with a win in the Project of the Year – Lighting category.
Energy Class B
Energy Class B
