CITY PT
Modern Post Top Lantern with T5 360° Area Optic
- Supplied with T5 360° area optic
- Suitable for exterior building and feature lighting
- TM66 Certified options available for specification
- Available in wide range of outputs, up to 16,700 lumens
- Modern, stylish post top lantern for city beautification projects
- Photocell option available
- Polycarbonate micro optic with glass cover
- Dark Sky Approvals on versions with 3000k and DALI options
- CRI: Ra>80
- Die-cast aluminium body finished in grey (RAL 9006) or black (RAL 9005)
- Supplied in neutral white (4000K) LED
- Up to 129 lumens per Watt efficacy
Product Filter
If you don’t have a part number, use the filter to find what you need. Select product and light source first to narrow the output and power options.
| Order Code | Description | lm | W | lm/W | Dia(mm) | H(mm) |
|---|---|---|---|---|---|---|
| CPTT4580WWB | 49W - 360° Area Optic - 3000K - Black | 5800 | 49 | 118 | 460 | 168 |
| CPTT4580WWBD | 49W - 360° Area Optic - 3000K - Black | 5800 | 49 | 118 | 460 | 168 |
| CPTT4580WWBDPC | 49W - 360° Area Optic - 3000K - Black | 5800 | 49 | 118 | 460 | 222 |
| CPTT4580WWBPC | 49W - 360° Area Optic - 3000K - Black | 5800 | 49 | 118 | 460 | 222 |
| CPTT4580WWG | 49W - 360° Area Optic - 3000K - Grey | 5800 | 49 | 118 | 460 | 168 |
| CPTT4580WWGD | 49W - 360° Area Optic - 3000K - Grey | 5800 | 49 | 118 | 460 | 168 |
| CPTT4580WWGDPC | 49W - 360° Area Optic - 3000K - Grey | 5800 | 49 | 118 | 460 | 222 |
| CPTT4580WWGPC | 49W - 360° Area Optic - 3000K - Grey | 5800 | 49 | 118 | 460 | 222 |
| CPTT4630NWB | 49W - 360° Area Optic - 4000K - Black | 6300 | 49 | 129 | 460 | 168 |
| CPTT4630NWBD | 49W - 360° Area Optic - 4000K - Black | 6300 | 49 | 129 | 460 | 168 |
| CPTT4630NWBDPC | 49W - 360° Area Optic - 4000K - Black | 6300 | 49 | 129 | 460 | 222 |
| CPTT4630NWBPC | 49W - 360° Area Optic - 4000K - Black | 6300 | 49 | 129 | 460 | 222 |
| CPTT4630NWG | 49W - 360° Area Optic - 4000K - Grey | 6300 | 49 | 129 | 460 | 168 |
| CPTT4630NWGD | 49W - 360° Area Optic - 4000K - Grey | 6300 | 49 | 129 | 460 | 168 |
| CPTT4630NWGDPC | 49W - 360° Area Optic - 4000K - Grey | 6300 | 49 | 129 | 460 | 222 |
| CPTT4630NWGPC | 49W - 360° Area Optic - 4000K - Grey | 6300 | 49 | 129 | 460 | 222 |
| CPTT4810WWB | 74W - 360° Area Optic - 3000K - Black | 8100 | 74 | 109 | 460 | 168 |
| CPTT4810WWBD | 74W - 360° Area Optic - 3000K - Black | 8100 | 74 | 109 | 460 | 168 |
| CPTT4810WWBDPC | 74W - 360° Area Optic - 3000K - Black | 8100 | 74 | 109 | 460 | 222 |
| CPTT4810WWBPC | 74W - 360° Area Optic - 3000K - Black | 8100 | 74 | 109 | 460 | 222 |
| CPTT4810WWG | 74W - 360° Area Optic - 3000K - Grey | 8100 | 74 | 109 | 460 | 168 |
| CPTT4810WWGD | 74W - 360° Area Optic - 3000K - Grey | 8100 | 74 | 109 | 460 | 168 |
| CPTT4810WWGDPC | 74W - 360° Area Optic - 3000K - Grey | 8100 | 74 | 109 | 460 | 222 |
| CPTT4810WWGPC | 74W - 360° Area Optic - 3000K - Grey | 8100 | 74 | 109 | 460 | 222 |
| CPTT4870NWB | 74W - 360° Area Optic - 4000K - Black | 8700 | 74 | 118 | 460 | 168 |
| CPTT4870NWBD | 74W - 360° Area Optic - 4000K - Black | 8700 | 74 | 118 | 460 | 168 |
| CPTT4870NWBDPC | 74W - 360° Area Optic - 4000K - Black | 8700 | 74 | 118 | 460 | 222 |
| CPTT4870NWBPC | 74W - 360° Area Optic - 4000K - Black | 8700 | 74 | 118 | 460 | 222 |
| CPTT4870NWG | 74W - 360° Area Optic - 4000K - Grey | 8700 | 74 | 118 | 460 | 168 |
| CPTT4870NWGD | 74W - 360° Area Optic - 4000K - Grey | 8700 | 74 | 118 | 460 | 168 |
| CPTT4870NWGDPC | 74W - 360° Area Optic - 4000K - Grey | 8700 | 74 | 118 | 460 | 222 |
| CPTT4870NWGPC | 74W - 360° Area Optic - 4000K - Grey | 8700 | 74 | 118 | 460 | 222 |
| CPTT41530WWB | 149W - 360° Area Optic - 3000K - Black | 15300 | 149 | 103 | 460 | 168 |
| CPTT41530WWBD | 149W - 360° Area Optic - 3000K - Black | 15300 | 149 | 103 | 460 | 168 |
| CPTT41530WWBDPC | 149W - 360° Area Optic - 3000K - Black | 15300 | 149 | 103 | 460 | 222 |
| CPTT41530WWBPC | 149W - 360° Area Optic - 3000K - Black | 15300 | 149 | 103 | 460 | 222 |
| CPTT41530WWG | 149W - 360° Area Optic - 3000K - Grey | 15300 | 149 | 103 | 460 | 168 |
| CPTT41530WWGD | 149W - 360° Area Optic - 3000K - Grey | 15300 | 149 | 103 | 460 | 168 |
| CPTT41530WWGDPC | 149W - 360° Area Optic - 3000K - Grey | 15300 | 149 | 103 | 460 | 222 |
| CPTT41530WWGPC | 149W - 360° Area Optic - 3000K - Grey | 15300 | 149 | 103 | 460 | 222 |
| CPTT41670NWB | 149W - 360° Area Optic - 4000K - Black | 16700 | 149 | 112 | 460 | 168 |
| CPTT41670NWBD | 149W - 360° Area Optic - 4000K - Black | 16700 | 149 | 112 | 460 | 168 |
| CPTT41670NWBDPC | 149W - 360° Area Optic - 4000K - Black | 16700 | 149 | 112 | 460 | 222 |
| CPTT41670NWBPC | 149W - 360° Area Optic - 4000K - Black | 16700 | 149 | 112 | 460 | 222 |
| CPTT41670NWG | 149W - 360° Area Optic - 4000K - Grey | 16700 | 149 | 112 | 460 | 168 |
| CPTT41670NWGD | 149W - 360° Area Optic - 4000K - Grey | 16700 | 149 | 112 | 460 | 168 |
| CPTT41670NWGDPC | 149W - 360° Area Optic - 4000K - Grey | 16700 | 149 | 112 | 460 | 222 |
| CPTT41670NWGPC | 149W - 360° Area Optic - 4000K - Grey | 16700 | 149 | 112 | 460 | 222 |
