MODLED

A high-performance backlit recessed module with opal diffuser, delivering uniform and consistent illumination.

  • Applications: Ideal for office spaces, task lighting and general area illumination
  • Construction: Pressed steel body in white (RAL 9010) for durability and clean finish
  • Body Sizes: Available in 3 sizes with lumen outputs from 2200 lm to 8800 lm
  • Energy Efficiency: Achieves up to 174 lm/W (lumens per watt) output
  • Superior Light Quality: Backlit LED array provides improved uniformity, eliminating dark spots and ensuring consistent illumination.
  • High Colour Rendering: CRI of Ra>80 ensures accurate colour representation
  • Diffuser Options: Opal or low-glare for visual comfort in workplace settings
  • Colour Temperatures: 3000K (Warm White), 4000K (Neutral White) or 5000K (Cool White) available on 600x600mm models
  • Installation: Modular design for easy fit in exposed T-bar ceilings
  • Emergency: Optional maintained emergency 3-hours variants providing safety during power outage
5 Years Warranty2 Years On-Site Warranty (T&C`s Apply)Vision OneVision ConnectVision Connect ProVision AirVision Air Pro
Product Filter

If you don’t have a part number, use the filter to find what you need. Select product and light source first to narrow the output and power options.

Instruction leaflet
Polar Curve
Order Code Description lm W lm/W L(mm) W(mm) D(mm)
MBL123220NW 16W - Opal diffuser - 4000K 2200 16 116 1195 295 35
MBL123220NWA3 16W - Opal diffuser - 4000K 2200 16 116 1195 295 35
MBL123220NWD 16W - Opal diffuser - 4000K 2200 16 116 1195 295 35
MBL123220NWD3 16W - Opal diffuser - 4000K 2200 16 116 1195 295 35
MBL123220NWDA3 16W - Opal diffuser - 4000K 2200 16 116 1195 295 35
MBL123220NWDD3 16W - Opal diffuser - 4000K 2200 16 116 1195 295 35
MBL123220NWDM3 16W - Opal diffuser - 4000K 2200 16 116 1195 295 35
MBL123220NWM3 16W - Opal diffuser - 4000K 2200 16 116 1195 295 35
MBLA66220CW 13W - Opal diffuser - 5000K 2200 13 169 595 595 35
MBLA66220CWA3 13W - Opal diffuser - 5000K 2200 13 169 595 595 35
MBLA66220CWD 13W - Opal diffuser - 5000K 2200 13 169 595 595 35
MBLA66220CWD3 13W - Opal diffuser - 5000K 2200 13 169 595 595 35
MBLA66220CWDA3 13W - Opal diffuser - 5000K 2200 13 169 595 595 35
MBLA66220CWDD3 13W - Opal diffuser - 5000K 2200 13 169 595 595 35
MBLA66220CWDM3 13W - Opal diffuser - 5000K 2200 13 169 595 595 35
MBLA66220CWM3 13W - Opal diffuser - 5000K 2200 13 169 595 595 35
MBLA66220NW 13W - Opal diffuser - 4000K 2200 13 169 595 595 35
MBLA66220NWA3 13W - Opal diffuser - 4000K 2200 13 169 595 595 35
MBLA66220NWD 13W - Opal diffuser - 4000K 2200 13 169 595 595 35
MBLA66220NWD3 13W - Opal diffuser - 4000K 2200 13 169 595 595 35
MBLA66220NWDA3 13W - Opal diffuser - 4000K 2200 13 169 595 595 35
MBLA66220NWDD3 13W - Opal diffuser - 4000K 2200 13 169 595 595 35
MBLA66220NWDM3 13W - Opal diffuser - 4000K 2200 13 169 595 595 35
MBLA66220NWM3 13W - Opal diffuser - 4000K 2200 13 169 595 595 35
MBLA66220WW 13W - Opal diffuser - 3000K 2200 13 169 595 595 35
MBLA66220WWA3 13W - Opal diffuser - 3000K 2200 13 169 595 595 35
MBLA66220WWD 13W - Opal diffuser - 3000K 2200 13 169 595 595 35
MBLA66220WWD3 13W - Opal diffuser - 3000K 2200 13 169 595 595 35
MBLA66220WWDA3 13W - Opal diffuser - 3000K 2200 13 169 595 595 35
MBLA66220WWDD3 13W - Opal diffuser - 3000K 2200 13 169 595 595 35
MBLA66220WWDM3 13W - Opal diffuser - 3000K 2200 13 169 595 595 35
MBLA66220WWM3 13W - Opal diffuser - 3000K 2200 13 169 595 595 35
MBL123330NW 27W - Opal diffuser - 4000K 3300 27 122 1195 295 35
MBL123330NWA3 27W - Opal diffuser - 4000K 3300 27 122 1195 295 35
MBL123330NWD 27W - Opal diffuser - 4000K 3300 27 122 1195 295 35
MBL123330NWD3 27W - Opal diffuser - 4000K 3300 27 122 1195 295 35
MBL123330NWDA3 27W - Opal diffuser - 4000K 3300 27 122 1195 295 35
MBL123330NWDD3 27W - Opal diffuser - 4000K 3300 27 122 1195 295 35
MBL123330NWDM3 27W - Opal diffuser - 4000K 3300 27 122 1195 295 35
MBL123330NWM3 27W - Opal diffuser - 4000K 3300 27 122 1195 295 35
MBLA66330CW 19W - Opal diffuser - 5000K 3300 19 174 595 595 35
MBLA66330CWA3 19W - Opal diffuser - 5000K 3300 19 174 595 595 35
MBLA66330CWD 19W - Opal diffuser - 5000K 3300 19 174 595 595 35
MBLA66330CWD3 19W - Opal diffuser - 5000K 3300 19 174 595 595 35
MBLA66330CWDA3 19W - Opal diffuser - 5000K 3300 19 174 595 595 35
MBLA66330CWDD3 19W - Opal diffuser - 5000K 3300 19 174 595 595 35
MBLA66330CWDM3 19W - Opal diffuser - 5000K 3300 19 174 595 595 35
MBLA66330CWM3 19W - Opal diffuser - 5000K 3300 19 174 595 595 35
MBLA66330NW 19W - Opal diffuser - 4000K 3300 19 174 595 595 35
MBLA66330NWA3 19W - Opal diffuser - 4000K 3300 19 174 595 595 35
MBLA66330NWD 19W - Opal diffuser - 4000K 3300 19 174 595 595 35
MBLA66330NWD3 19W - Opal diffuser - 4000K 3300 19 174 595 595 35
MBLA66330NWDA3 19W - Opal diffuser - 4000K 3300 19 174 595 595 35
MBLA66330NWDD3 19W - Opal diffuser - 4000K 3300 19 174 595 595 35
MBLA66330NWDM3 19W - Opal diffuser - 4000K 3300 19 174 595 595 35
MBLA66330NWM3 19W - Opal diffuser - 4000K 3300 19 174 595 595 35
MBLA66330WW 19W - Opal diffuser - 3000K 3300 19 174 595 595 35
MBLA66330WWA3 19W - Opal diffuser - 3000K 3300 19 174 595 595 35
MBLA66330WWD 19W - Opal diffuser - 3000K 3300 19 174 595 595 35
MBLA66330WWD3 19W - Opal diffuser - 3000K 3300 19 174 595 595 35
MBLA66330WWDA3 19W - Opal diffuser - 3000K 3300 19 174 595 595 35
MBLA66330WWDD3 19W - Opal diffuser - 3000K 3300 19 174 595 595 35
MBLA66330WWDM3 19W - Opal diffuser - 3000K 3300 19 174 595 595 35
MBLA66330WWM3 19W - Opal diffuser - 3000K 3300 19 174 595 595 35
MBL123440NW 35W - Opal diffuser - 4000K 4400 35 126 1195 295 35
MBL123440NWA3 35W - Opal diffuser - 4000K 4400 35 126 1195 295 35
MBL123440NWD 35W - Opal diffuser - 4000K 4400 35 126 1195 295 35
MBL123440NWD3 35W - Opal diffuser - 4000K 4400 35 126 1195 295 35
MBL123440NWDA3 35W - Opal diffuser - 4000K 4400 35 126 1195 295 35
MBL123440NWDD3 35W - Opal diffuser - 4000K 4400 35 126 1195 295 35
MBL123440NWDM3 35W - Opal diffuser - 4000K 4400 35 126 1195 295 35
MBL123440NWM3 35W - Opal diffuser - 4000K 4400 35 126 1195 295 35
MBL126440NW 38W - Opal diffuser - 4000K 4400 38 116 1195 595 35
MBL126440NWA3 38W - Opal diffuser - 4000K 4400 38 116 1195 595 35
MBL126440NWD 38W - Opal diffuser - 4000K 4400 38 116 1195 595 35
MBL126440NWD3 38W - Opal diffuser - 4000K 4400 38 116 1195 595 35
MBL126440NWDA3 38W - Opal diffuser - 4000K 4400 38 116 1195 595 35
MBL126440NWDD3 38W - Opal diffuser - 4000K 4400 38 116 1195 595 35
MBL126440NWDM3 38W - Opal diffuser - 4000K 4400 38 116 1195 595 35
MBL126440NWM3 38W - Opal diffuser - 4000K 4400 38 116 1195 595 35
MBLA66440CW 26W - Opal diffuser - 5000K 4400 26 169 595 595 35
MBLA66440CWA3 26W - Opal diffuser - 5000K 4400 26 169 595 595 35
MBLA66440CWD 26W - Opal diffuser - 5000K 4400 26 169 595 595 35
MBLA66440CWD3 26W - Opal diffuser - 5000K 4400 26 169 595 595 35
MBLA66440CWDA3 26W - Opal diffuser - 5000K 4400 26 169 595 595 35
MBLA66440CWDD3 26W - Opal diffuser - 5000K 4400 26 169 595 595 35
MBLA66440CWDM3 26W - Opal diffuser - 5000K 4400 26 169 595 595 35
MBLA66440CWM3 26W - Opal diffuser - 5000K 4400 26 169 595 595 35
MBLA66440NW 26W - Opal diffuser - 4000K 4400 26 169 595 595 35
MBLA66440NWA3 26W - Opal diffuser - 4000K 4400 26 169 595 595 35
MBLA66440NWD 26W - Opal diffuser - 4000K 4400 26 169 595 595 35
MBLA66440NWD3 26W - Opal diffuser - 4000K 4400 26 169 595 595 35
MBLA66440NWDA3 26W - Opal diffuser - 4000K 4400 26 169 595 595 35
MBLA66440NWDD3 26W - Opal diffuser - 4000K 4400 26 169 595 595 35
MBLA66440NWDM3 26W - Opal diffuser - 4000K 4400 26 169 595 595 35
MBLA66440NWM3 26W - Opal diffuser - 4000K 4400 26 169 595 595 35
MBLA66440WW 26W - Opal diffuser - 3000K 4400 26 169 595 595 35
MBLA66440WWA3 26W - Opal diffuser - 3000K 4400 26 169 595 595 35
MBLA66440WWD 26W - Opal diffuser - 3000K 4400 26 169 595 595 35
MBLA66440WWD3 26W - Opal diffuser - 3000K 4400 26 169 595 595 35
MBLA66440WWDA3 26W - Opal diffuser - 3000K 4400 26 169 595 595 35
MBLA66440WWDD3 26W - Opal diffuser - 3000K 4400 26 169 595 595 35
MBLA66440WWDM3 26W - Opal diffuser - 3000K 4400 26 169 595 595 35
MBLA66440WWM3 26W - Opal diffuser - 3000K 4400 26 169 595 595 35
MBL126600NW 45W - Opal diffuser - 4000K 6000 45 111 1195 595 35
MBL126600NWA3 45W - Opal diffuser - 4000K 6000 45 111 1195 595 35
MBL126600NWD 45W - Opal diffuser - 4000K 6000 45 111 1195 595 35
MBL126600NWD3 45W - Opal diffuser - 4000K 6000 45 111 1195 595 35
MBL126600NWDA3 45W - Opal diffuser - 4000K 6000 45 111 1195 595 35
MBL126600NWDD3 45W - Opal diffuser - 4000K 6000 45 111 1195 595 35
MBL126600NWDM3 45W - Opal diffuser - 4000K 6000 45 111 1195 595 35
MBL126600NWM3 45W - Opal diffuser - 4000K 6000 45 111 1195 595 35
MBL126880NW 82W - Opal diffuser - 4000K 8800 82 107 1195 595 35
MBL126880NWA3 82W - Opal diffuser - 4000K 8800 82 107 1195 595 35
MBL126880NWD 82W - Opal diffuser - 4000K 8800 82 107 1195 595 35
MBL126880NWD3 82W - Opal diffuser - 4000K 8800 82 107 1195 595 35
MBL126880NWDA3 82W - Opal diffuser - 4000K 8800 82 107 1195 595 35
MBL126880NWDD3 82W - Opal diffuser - 4000K 8800 82 107 1195 595 35
MBL126880NWDM3 82W - Opal diffuser - 4000K 8800 82 107 1195 595 35
MBL126880NWM3 82W - Opal diffuser - 4000K 8800 82 107 1195 595 35
